Product Details:
|
Nominal Capacity: | 200Ah | Maximum Charge Current: | 100A |
---|---|---|---|
Peak Discharge Current: | 150A(1S) | Communication: | CAN/RS232/RS485 |
Dimension: | L442 X W580 X H220 Mm | Cycle Life: | 6000 Cycles |
Net Weight: | 87Kg | Country Of Origin: | China |
Highlight: | 48V Base Station Battery,5KWh Base Station Battery,100A Base Station Battery |
Product Technical Parameters:
Item | Spec |
Model No. | RD-LR48200 |
Nominal Voltage(V) | 48/51.2 |
Nominal Capacity(Ah) | 200 |
Energy(Wh) | 9600/10240 |
Dimension(mm) | L442xW580xH185 |
Weight(Kg) | 88/92 |
Discharge Cut-off Voltage(V) | 40.5(15S)/43.2(16S) |
Charge Cut-off Voltage(V) | 54.7(15S)/58.4(16S) |
Communication Port | RS485,RS232 CAN |
Cell serial numbert(pcs | 15S/16S |
Working Temperature | -10°C~60°C |
Design life | 10+Years (25°C/77°F) |
Cycle Life | >6000,25°C/77°F,80%DOD |
Certification | CE/UN38.3 |
Maximum continuous charge current | 100A |
Maximum continuous discharge current | 100A |
At Tuorde, we understand that every base station has different power requirements and specifications. That's why we offer a variety of customization options for our Base Station Battery to meet your specific needs.
