48V 5KWh Telecom Base Station Battery 100A Discharge

48V 5KWh Telecom Base Station Battery 100A Discharge
48V 5KWh Telecom Base Station Battery 100A Discharge

Large Image :  48V 5KWh Telecom Base Station Battery 100A Discharge

Product Details:
Place of Origin: China
Brand Name: Tuorde
Certification: UN38.8/MSDS/CE
Model Number: TRD-LR48200

48V 5KWh Telecom Base Station Battery 100A Discharge

Description
Nominal Capacity: 200Ah Maximum Charge Current: 100A
Peak Discharge Current: 150A(1S) Communication: CAN/RS232/RS485
Dimension: L442 X W580 X H220 Mm Cycle Life: 6000 Cycles
Net Weight: 87Kg Country Of Origin: China
Highlight:

48V Base Station Battery

,

5KWh Base Station Battery

,

100A Base Station Battery



Product Technical Parameters:



Item Spec
Model No. RD-LR48200
Nominal Voltage(V) 48/51.2
Nominal Capacity(Ah) 200
Energy(Wh) 9600/10240
Dimension(mm) L442xW580xH185
Weight(Kg) 88/92
Discharge Cut-off Voltage(V) 40.5(15S)/43.2(16S)
Charge Cut-off Voltage(V) 54.7(15S)/58.4(16S)
Communication Port RS485,RS232 CAN
Cell serial numbert(pcs 15S/16S
Working Temperature -10°C~60°C
Design life 10+Years (25°C/77°F)
Cycle Life >6000,25°C/77°F,80%DOD
Certification CE/UN38.3
Maximum continuous charge current 100A
Maximum continuous discharge current 100A



Customization Options

At Tuorde, we understand that every base station has different power requirements and specifications. That's why we offer a variety of customization options for our Base Station Battery to meet your specific needs.

  • Capacity: Our battery has a nominal capacity of 200Ah, but we can customize it to have a higher or lower capacity depending on your requirements.
  • Voltage: The nominal voltage of our battery is 51.2V, but we can adjust it to meet the voltage requirements of your base station.
  • Size: The standard dimension of our battery is L442 X W580 X H220 mm, but we can customize the size to fit your base station's space constraints.
  • Weight: Our battery has a net weight of 87Kg, but we can make it lighter or heavier depending on your needs.
  • Energy: With an energy capacity of 10240Wh, our battery can power your base station for a long time. However, we can customize the energy capacity to match your power requirements.
